Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig

1か月あたり1Set/セット
MOQ
negotiable
価格
Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
製品名: コア・ドリリング・リグ コア・ドリリング・マシン
名前: 掘削装置,水井掘削装置,核掘削装置
タイプ: 核掘削装置
キーワード: 逆の循環の掘削装置
パワータイプ: ディーゼル
電力(w): 132kW
掘削深度: 500m
掘削直径: 140-400MM
持ち上げる力: 12KN
回転式トルク: 8000-12000Nm
回転速度: 40~160rpm
使用圧力: 1.7-3.5MPA
ドリルパイプの直径: 76/89/102/114mm
ドリルパイプの長さ: 1.5/2.0/3.0m
応用: コアリングマシン、石炭、地質探査
使用法: 石炭,水井.コアサンプル
特徴: 高く鋭い効率、多機能油圧制御
提供されるアフターサービス: オンラインサポート
重さ: 12000kg
ハイライト:

reverse circulation core drill rig

,

soil investigation drilling machine

,

core sample drilling rig with warranty

基本情報
起源の場所: 浙江省、中国
ブランド名: SANROCK
証明: CE ISO 9001:2015
モデル番号: SR-500RC
お支払配送条件
パッケージの詳細: 機械用のヌードパッケージ、スペアパーツ用の木製ボックスパッケージ、または顧客の需要。
受渡し時間: 15~26営業日
支払条件: L/C、D/A、D/P、T/T、ウェスタンユニオン、マネーグラム
供給の能力: 月額5000Set/セット
製品の説明

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 0

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 1

Reverse Circulation Core Drill Rig for Soil Investigation

This specialized Reverse Circulation (RC) core drill rig is engineered for high-efficiencysoil and subsurface investigation, providing reliable sampling for geotechnical studies,environmental assessments, and construction planning. Designed to deliver undisturbed,

contamination-free core samples from various soil layers, it ensures accurate data collection

for analyzing soil composition, stability, and stratification.The rig employs a reverse circulation system using dual-wall drill rods, where air or fluid is

pumped downward through the outer annulus, enabling rapid penetration while soil and

core samples are cleanly retrieved through the inner tube. This sealed process minimizes

external contamination and preserves the original structure of soft, loose, or layered

soils—critical for precise laboratory testing and engineering evaluations.

Built with a modular and compact structure, the rig offers easy transport and quick setup

in constrained or remote areas.

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 2Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 3Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 4Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 5Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 6Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 7

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 8


Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 9

This is just a part of the overseas clients who came to our company to negotiate cooperation, sign contracts and take photos.
We welcome more overseas clients to come to our company for negotiation and cooperation.

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 10

Product Description


Drilling capacity
Drilling depth(m)
500
The hole diameter(mm)
140-400
Drill pipe diameter(mm)
76/89/102/114
Drill pipe length(m)
1.5/2/3
Axial pressure(kN)
100
Drive head
Rotation torque(N.m)
8000-12000
Rotation speed(rpm)
40-160
Stroke(m)
1.7-3.5
Rig lifting force(kN)
300
Feeding capacity(kN)
150
Rapid rise speed(m/min)
20
Fast feeding speed(m/min)
40
Power Unit
Rated power/speed(kW/rpm)
132/2400
Tool winch capacity
Lifting force(kN)
20
Air compressor
Air pressure(MPA)
1.7-3.5
Air consumption(m³/min)
17-42
Equipped with hammer(Reverse circulation)
Medium and high pressure series
Crawler chassis
Walking speed(km/h)
2.5
Climbing angle(°)
30
Dimension
Transport(mm)
6450*2100*2700
Working(mm)
4500*4000*7000
Weight
Weight(t)
12

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 11

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 12


Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 13Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 14Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 15

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 16Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 17Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 18Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 19Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 20

Company Profile

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 21

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 22

Core Sample Drilling Rig Soil Investigation Drilling Machine Reverse Circulation Core Drill Rig 23

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.


2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.


3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.


4.How is your quality control? A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
