Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod

25セット/セット/月
MOQ
negotiable
価格
Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
製品名: 掘削棒
マシンタイプ: 掘削ツール
使用: 鉱石採掘,井戸掘削,石炭採掘,採石場,岩石掘削/水井採掘
タイプ: ドリル管、ドリル棒
アプリケーション: 大理石採石場、ダイヤモンド掘削、削岩機とロックビットと接続、バックホー
使用法: 削岩、採掘、穴あけ、石炭採掘、地質掘削
処理型: 鋳造,鋳造,低価格 トンガパイプ 掘削棒,熱処理
アドバンテージ: 高品質の工場価格 高強度 信頼性の高い材料 長寿命
テクノロジー: 乱すプロセスとナイトライド処理
長さ: 1M、1.5M、2M、2.5M、3M、6M
直径: 50~159mm
糸: 2 3/8 インチ API レジストレーション スレッド、3 1/2 インチ API レジストレーション
ハイライト:

spiral drill rod high torsional strength

,

auger drill rod manufacturer

,

drill pipe spiral drilling rod

基本情報
起源の場所: 浙江省、中国
ブランド名: SANROCK
証明: CE ISO 9001:2015
モデル番号: ツイストドリルパイプ
お支払配送条件
パッケージの詳細: 機械用のヌードパッケージ、スペアパーツ用の木製ボックスパッケージ、または顧客の需要。
受渡し時間: 15-25日
支払条件: L/C、D/A、D/P、T/T、ウェスタンユニオン、マネーグラム
供給の能力: 月額5000Set/セット
製品の説明

Versatile Adaptability: Suitable for rotary, percussive, or auger drilling systems,

it excels in diverse applications including mineral exploration, foundation piling,geothermal drilling, and underground mining.

Advantages of Twist Drill Rod (Auger Drill Rod)

The twist drill rod, renowned for its helical groove design, offers multipleadvantages in drilling operations:

Efficient Cuttings Removal: The continuous spiral flutes create a natural pathwayfor rapid ejection of rock debris, soil, or coal cuttings, preventing borehole blockageand reducing downtime for manual cleaning.

Enhanced Cooling & Lubrication: The helical geometry promotes airflow or drilling

fluid circulation along the rod, dissipating heat generated during high-speed rotations

and minimizing friction-induced wear on the bit.

High Torsional Strength: Fabricated from hardened alloy steel with optional carbide coatings,

it withstands extreme torque loads and abrasive environments, ensuring durability in hard rock,

coal seams, or compacted soils.

Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 0









Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 1Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 2

Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 3

Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 4

Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 5



Product Description

Diameter(mm) Thickness(mm) Thickening type Length(mm) Thread Board shank slot
76 5-8mm IU 1000/ 1500/ 2000/ 2500/ 3000/ 4000/ 5000/ 6000 2 3/8API REG Double buckle
Single buckle






89 6-9.35mm IU 1000/ 1500/ 2000/ 2500/ 3000/ 4000/ 5000/ 6000 2 3/8 IF Double buckle
Single buckle






102 7-8.38mm IU/IEU 1500/ 2000/ 2500/ 3000/ 4000/ 5000/ 6000 2 7/8 IF 3 1/2 REG Double buckle
Single buckle





114 6-9.35mm IU 1500/ 2000/ 2500/ 3000/ 4000/ 5000/ 6000 2 7/8 IF 3 1/2 IF/REG Double buckle
Single buckle





127 9mm IU 1500/ 2000/ 2500/ 3000/ 4000/ 5000/ 6000 3 1/2 IF Double buckle
Single buckle





140 8-12mm IU 3000/ 4500/ 5000/ 6000 4 1/2 REG or 4FH Double buckle
Single buckle



Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 6Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 7

Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 8



Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 9

Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 10Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 11



Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 12

Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 13

Company Profile

Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 14

Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 15

Manufacturer Drill Pipe Spiral Drilling Rod High Torsional Strength Auger Drill Rod 16

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill rod,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.




3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.




4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
