Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

1 セット
MOQ
negotiable
価格
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
製品名: スクロールエアコンプレッサー,エアコンプレッサーマシン
Name: ディーゼルねじ空気圧縮機
パワー: 410kw
電力源: ディーゼル
圧力: 21-25バール/21-34バール
空気消費量: 31〜29m2/min 36.5-32m2/min
スピード: 1600/1400rpm 1830/1400rpm
燃料タンク容量: 700L
潤滑油容量: 120L
冷却方法: 空気/利用できる水冷両方
適用する: 鉱山プロジェクト,石炭,鉱石
タイプ: スクロール
コアコンポーネント: PLC、圧力容器、エンジン、モーター、ポンプ、ベアリング
構成: 固定
寸法(長さ*幅*高さ): 4100*1800*2050mm
体重: 5600kg
ハイライト:

Diesel Screw Air Compressor

,

Rotary Screw Air Compressor

,

Rotary Screw Drive Air Compressor

基本情報
起源の場所: チェジアン,中国
ブランド名: SANROCK
証明: CE ISO 9001:2015
モデル番号: カスタマイズ
お支払配送条件
パッケージの詳細: 機械のヌードパッケージ 部品の木箱パッケージ または顧客の要求
受渡し時間: 18~25 営業日
支払条件: 信用状、D/A、D/P、T/T、ウェスタンユニオン、マネーグラム
供給の能力: 5000セット/セット/月
製品の説明

screw air compressor used with water well drilling rig
This specialized rotary screw air compressor is engineered to deliver high-efficiency compressed air supply for water well drilling operations.
Featuring robust twin-screw technology, to power down-the-hole hammers and rotary drilling systems. superior cooling and lubrication for extended duty cycles in harsh drilling environments.
Integrated with vibration-resistant components and heavy-duty filtration systems, this compressor maintains high performance under dust and high-temperature conditions.
Automatic load/unload controls and energy-saving VFD options enhance fuel efficiency for mobile drilling rig configurations. With protection rating and corrosion-resistant coatings, it meets rigorous drilling industry standards for reliability in borewell construction and geothermal drilling applications.

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 0Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 1

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 2

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 3



Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 4Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 5

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 6Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 7

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 8

Products Description

Brand Name:Sanrock
Product name: screw air compressor
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600


Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 9

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 10Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 11Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 12
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 13Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 14





Company Profile

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 15

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 16

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor 17
